 CPU |
| |
Support
ZIF white socket for :
Intel
Pentium® Processor 75-233MHz
(Auto Detect & Setup Intel P55C Processor)
AMD K86 K6-2 Processor Support K6-2 with K6-2 Hack
Cyrix 6x86 Processor Support
ZIF Socket 7 for Intel Pentium® OverDrive® Processor,
MMX Processor
|
| Chipset |
| |
Intel
82430 HX PCIset
UMC 8669/SMC 669 I/O chip
Adaptec 7880 SCSI chip |
| FSB |
| |
Supports
50 to 66MHz FSB adjustments in 4 steps |
| Main
Memory |
| |
4 banks 72 pin SIMM module socket on
board Use 4/8/16/32/64/128 MB 60~70 ns SIMM module
DRAM 8 ~ 512 MB DRAM size
Support Fast Page/EDO DRAM access mode |
| Slots |
| |
4x
PCI 32-bit slots (RAID Port Ready rev 3 board only)
4x ISA 16-bit slots |
| On-Board
IDE |
| |
2xPCI
Bus Master IDE ports (up to 4 IDE Devices)
Support PIO Mode 3,4 IDE & ATAPI CD-ROM |
| Audio |
| |
No
onboard sound |
| On-Board
Peripherals |
| |
Two
channels Enhanced IDE channels on board. (Using IRQ 14, 15)
Support Mode 3, 4 IDE & ATAPI CD-ROM
Using Adaptec 7880 Ultra Wide chipset
Supports one SCSI-2 or Ultra 8 bit SCSI port
Supports one Wide or Ultra Wide port
Supports 2 16550 COM ports. (Using IRQ 3, 4)
Supports 1 EPP/ECP LPT port. (Using IRQ 7 or 5 & DMA 3 or 1)
Supports 1 1.44 MB Floppy port. (Using DMA 2 & IRQ 6)
Supports PS/2 Mouse (Using IRQ 12)
Supports PS/2 Keyboard |
| BIOS |
|
|
128KB
FLASH EEPROM
Award PCI BIOS with green
plug and play features supportt |
| Dimension |
| |
?x?mm
ATX Form Factor, 6 layers PCB |
| Mounting |
| |
9
mounting holes. |
|
